202 Stainless Steel Plates Stockist in Bahrain, ASTM A193 SS Plates Supplier, 309 Stainless Steel Plates Supplier in Bahrain, 201 Stainless Steel Plates Stockist, 301 Stainless Steel Plates Supplier in Bahrain
Neelkamal Alloy LLP is a remakable Stainless Steel Plate Supplier in Bahrain. Our Stainlee Steel Plate line deals with a vast variety of SS 301 Plates such as SS 304 Plate, SS 316L, and AISI SS 316L Plate, which can be used in different industrial and commercial operations. All our ASTM A240 310S Stainless Steel Plates, 904L Stainless Steel Plates are manufactured with great regards to ISO/International Standards that assure long-term performance and durability. Every batch is subjected to rigorous chemical and mechanical tests like tensile strength, hardness, and analysis of corrosion resistance. Our plates come in cold and hot rolled process and are produced using the highest quality materials such as chromium, nickel, and molybdenum to fit the toughest of operating environments.
Neelkamal Alloy LLP is highly recommended Stainless Steel Plates Stockist in Bahrain, having high-quality SS Plates such as 320 Stainless Steel Plate, 310 Stainless Steel Plates which has good heat and corrosion resistance. We have our plates that are in line with ISO and International Standards, giving them high quality and reliability. All products are subject to extensive chemical and mechanical testing to satisfy the challenging industrial needs. The ASMT A193 Stainless Steel Plates are perfect for use in different application areas, including heat exchangers, petrochemical plants, marine equipment, power generation, furnaces, and food processing units.
Are you interested to Buy ?
Get Updated Price from Neelkamal Alloys LLP
Stainless Steel TP 304 Plates Supplier in Bahrain, UNS S30215 SS Plate Supplier,904L Stainless Steel Plates Supplier, ASTM A240 310S Stainless Steel Plates, SS / AISI 316 Plate Stockist, 316 stainless steel plate Supplier and Exporter in Bahrain, SS 304 Plates Dealer in Bahrain
Neelkamal Alloy LLP is a notable Stainless Steel Plates Exporter in Bahrain with a variety of ASTM A240 Stainless Steel Plates in different sizes and lengths including, 1000mm x 2000mm, 1250mm x 2500mm and other custom cuts. Our Stainless Steel 316L Plates are of high quality and capative price to deliver great value on all applications. We also have high-quality Stainless Steel Round Bar if the intended use is in different industries. Plates come in different tempers of SS Plate depending on the application and can satisfy particular strength and flexibility criteria. Neelkamal Alloys LLP is a well-known Stainless Steel Plate Manufacturer of India.
Specification of Stainless Steel 317L Cold Rolled Plates
As the reliable Stainless Steel Plate Supplier in Bahrain, we provide standard specification for Stainless Steel Plate.
| SS Plate(Hot rolled, cold rolled) | |
| Size Avaliable | 5mm to 100 mm in width of 1000mm, 1250mm, 1500mm, 2000mm, 2500mm |
| MOQ | 100 kg’s to Production Qty’s |
| Delivery time | Promptly (Stock) or 10-40 days (Production) |
| Stock | Available |
| MTC | Mill TC EN 10204 3.1, Third Party Inspection, NDT/DT Test Reports |
| Surface Finish | 2B, 2D, BA, 3B, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed |
| Manufacturer | Jindal Stainless JSL, Aperam, POSCO, DKC Korea, Outokumpu, Baosteel, Arcelor Mittal, TISCO, Nippon Metal, VDM |
| Origin | Indian Origin, US Origin, Japanese Origin, Thailand Origin, European Origin |
Types of Stainless Steel Plate
Stainless Steel Plate are divided into several parts. Stainless Steel Plate Types are classified into various segments which includes the following.
Why Neelkamal Alloys LLP for Stainless Steel Plate?
Documentations
Documentations is provided with product for assurity of product, supplying Tax Invoice, Material test certificates (MTC), packaging list and Lorry Receipt (LR) copy of transport.
Marking and Packing
All of our products are labeled with the lot number, size, grade, degree, and our logo. Furthermore, for safer delivery, products are put in wooden crates/pallets/boxes or shrink-wrapped
Are you interested to Buy ?
Get Updated Price from Neelkamal Alloys LLP
UNS S31803 Stainless Steel Plates Weight Chart
| Thickness | Plate Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
TP 316H Stainless Steel Plates Size Chart
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in mm) |
| .125" | 3.18mm |
| .134" | 3.40mm |
| .156" | 3.96mm |
| .187" | 4.75mm |
| .250" | 6.35mm |
| .312" | 7.92mm |
| .375" | 9.53mm |
| .500" | 12.7mm |
| .600" | 15.9mm |
| .750" | 19.1mm |
| .875" | 22.2mm |
| 1" | 25.4mm |
| 1.125" | 28.6mm |
| 1.250" | 31.8mm |
| 1.500" | 38.1mm |
| 1.750" | 44.5mm |
| 2" | 50.8mm |
| 2.500" | 63.5mm |
| 3" | 76.2mm |
Stainless Steel TP 304 Plates Chemical Structure
| Type | Grade | ASTM A240 Chemical Composition | |||||||||
| ASTM(A240M) | Others(JIS) | C | Si | Mn | P | S | Ni | Cr | Mo | Others | |
| Austenitic Steels | 304 | SUS304 | ≤0.07 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/10.5 | 17.5/19.5 | ― | N≤0.10 |
| 304L | SUS304L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/12.0 | 17.5/19.5 | ― | N≤0.10 | |
| 310S | SUS310S | ≤0.08 | ≤1.50 | ≤2.00 | ≤0.045 | ≤0.030 | 19.0/22.0 | 24.0/26.0 | ― | ||
| 316 | SUS316 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | N≤0.10 | |
| 316L | SUS316L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | N≤0.10 | |
| 316H | 0.04/0.10 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | |||
| 317L | SUS317L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 11.0/15.0 | 18.0/20.0 | 3.0/4.0 | N≤0.10 | |
| 321 | SUS321 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 9.0/12.0 | 17.0/19.0 | ― | N≤0.10Ti:5ʷʢC+Nʣ/0.70 | |
| 347 | SUS347 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 9.0/13.0 | 17.0/19.0 | ― | Nb:10ʷC/1.00 | |
A240 SS 310 Hot Rolled Plates Mechanical Properties
| Type | Mechanical Properties for Stainless Steel Plates | |||||||
|---|---|---|---|---|---|---|---|---|
| ASTM(A240M) | Others(JIS) | Tensile Properties | Hardness | |||||
| Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation (%) | HBW | HRBW | ||||
| AusteniticSteels | 304 | SUS304 | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | |
| 304L | SUS304L | ≥170 | ≥485 | ≥40 | ≤201 | ≤92 | ||
| 310S | SUS310S | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 316 | SUS316 | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 316L | SUS316L | ≥170 | ≥485 | ≥40 | ≤217 | ≤95 | ||
| 317L | SUS317L | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 321 | SUS321 | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 347 | SUS347 | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | ||
| N08904/904L | SUS890L | ≥220 | ≥490 | ≥35 | ≤196 | ≤90 | ||
321L Stainless Steel Plate Surface Finish
| Plate Surface finish | Thickness (mm) | Width (max mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed plate | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled plate | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
Applications of Stainless Steel Plate
- Oil and Gas Processing
- Marine Engineering Industry
- Defense Applications
- Power Plants
- Automobile Industry
- Pulp and Paper
- Refinery & Petrochemicals
Stainless Steel Plate Supplier and Stockist in Bahrain
- Neelkamal Alloys LLP
Our Stainless Steel Plate is used in the following projects
As an emerging Stainless Steel Plate Supplier in Bahrain, we have supplied our 2507 Stainless Steel Plates in various projects like Hormoz New Oil Refinery - Iran, Ruwais Refinery Complex (United Arab Emirates), Al Zour Refinery- Kuwait and ADMA-OPCO - Umm Shaif Gas (USGIF) Abu Dhabi. We are known for our premium quality Stainless Steel Plate Supplier in Bahrain. We have supplied our products to numerous locations worldwide.
17 4-PH Stainless Steel Plates to Ruwais Refinery Complex (Oman)
304 Stainless Steel Plates to ADMA-OPCO - Umm Shaif Gas (USGIF) Abu Dhabi
309 S Stainless Steel Plates to Al Zour Refinery- Kuwait
304L Stainless Steel Plates to Hormoz New Oil Refinery - Iran
Stainless Steel Plates Supplier,Exporter in Bahrain
Neelkamal Alloys LLP has become one of the Exporters and Suppliers of TP 316H Stainless Steel Plates in Bahrain because of its quality and performance. Even these are containers of Stainless Steel Plate that we supply/export every month to different customers via ports of Bahrain.
